Robust connector system specifically designed for demanding environments
Form, fit and function replacement for ITW McMurdo RED range
The LMR Series of rack and panel connectors from Weald Electronics provide a form, fit and function alternative to the ITW McMurdo Connectors RED Range which was made obsolete in 2024. Most residual stock of this widely used connector family has now been consumed but specialist connector distributor Lane Electronics is able to maintain supply to existing and new customers with a direct alternative from its sister company, Weald Electronics.
Matching the technical performance and dimensions of the RED Range, the Weald LMR series is a compact but heavy-duty rectangular rack and panel connector system that is designed to provide a drop-in replacement to the RED Range for Line Removable Units (LRUs) and is particularly suited for use in rugged conditions where reliability is essential, and space and accessibility are a premium.
The LMR range offers four connector sizes, providing 8, 16, 24 and 32 ways with low insertion force and polarised blind-mate moulded insulators. Each of the male and female halves of the connector system consists of a combined high-performance Diallyl-Phthalate (DAP) moulded insulator and stainless-steel mounting plate (the ITW McMurdo Connectors RED Range offered DAP and a lower temperature grade Nylon) fitted with gold plated low insertion force blade contacts rated for 500+ operations.
The insulator form has generous polarising and pre-mating features which engage before contacts touch that makes it ideally suited for inaccessible applications and the female half is fitted with floating mounting bushes to further enhance the self-aligning functionality. Contact rating is a high 5A continuous across all contacts simultaneously at 100°C and the complete connector assembly meets a climate category of 55/125/56 (-55°C to +125°C temperature range).
With high-quality materials and excellent current carrying characteristics the LMR range of connectors provide reliable connectivity for line-replaceable industrial electronics units such as industrial measurement and configurable automation and robotics.
Main Features include:
- Rugged construction
- 180° polarised
- Floating bushes to assist alignment
- Excellent current carrying characteristics
- Available in four sizes with 8, 16, 24 and 32 contacts
- 5A current rating
- Working voltage 800V DC or AC peak
- UL-94 V-0 rated flame-retardant
- Diallyl-Phthalate (DAP) insulators
- Working temperature -55°C to +125°C
Lane Electronics has now introduced the rugged LMR connector series to its popular on-line store with all four sizes, both male and female on ex-stock availability. With just a few clicks of a computer mouse, the full LMR range can be viewed on-line, with options to access supporting catalogue documentation and full pricing options. 3D models and customised quotations can be requested and left with the Lane Electronics team of specialists, around the clock on any day of the year, for a characteristically quick response from their knowledgeable customer service team.
Weald Electronics is a UK connector manufacturer with more than 40 years of experience in the design, manufacture, and testing of high-performance connector systems for demanding applications as well as a wide range of accessories including panel sealing gaskets, and EMC and strain relief backshells.
All Weald Electronics products are available from the leading franchised distributor Lane Electronics and more information on the Weald LMR can be found here https://www.wealdelectronics.com/products/lmr-rack-and-panel-connectors
Lane Electronics is a franchised distributor for many of the industry’s leading electrical and electronic connector manufacturers including EATON Souriau, CINCH Fibreco, HUBER+SUHNER, HellermannTyton, Positronic, Nicomatic and LEMO. With a strong commitment to quality with IECQ – CECC, ISO and QPL approvals, Lane Electronics has a policy of holding large stocks and is also franchised to assemble connectors to customer specific requirements.
For more information call +44 (0) 1403 790 661, email [email protected] or visit https://www.fclane.com/
