With the IQH3-FP-V1 and IQT3-FP-IO-V1 RFID read/write devices, Pepperl+Fuchs is introducing two new
high-performance products for solving identification tasks, combining the advantages of high-frequency RFID
with a unique sensing range, which is space-saving in a modern, compact enclosure. Based on the proven
and globally standardized high-frequency RFID technology (13.56 MHz) in accordance with ISO 15693, the
RFID read/write devices offer fully reliable and interference-free read/write results for all near-field
applications.
The devices have a one-of-a-kind detection range of up to 30 cm (adjustable) for this class on the market
and the ability to detect up to 20 RFID tags with a single read operation. This combination gives users the
greatest possible flexibility and freedom in adapting the RFID read/write devices to the specific parameters of
their application.
The new IQH3-FP-V1 and IQT3-FP-IO-V1 RFID read/write devices
In addition to the high degree of versatility in their application, the new RFID read/write devices also
demonstrate excellent process reliability. By automatically checking their own resonance frequency, the
devices are able to automatically adapt to interference caused by the installation location, surrounding
materials or interference radiation in order to maintain full detection power.
For seamless integration into the system environment, the RFID read/write devices are available in two
versions. The IQT3-FP-IO-V1 has an integrated IO-Link interface, while the IQH3-FP-V1 can be integrated
via the IDENTControl evaluation units from Pepperl+Fuchs.
